Benefits of Spherical Hob in Hydromill Cutting
Cost-Effective Construction: The implementation of spherical hobs significantly lowers the expenses associated with hydromill cutting in hard rock, leading to faster project timelines.
Streamlined Process: There’s no requirement for precutting holes, which simplifies the necessary construction equipment and processes.
Prolonged Operation: The hob-tooth hydromill wheel allows for continuous operation for up to 100 hours, decreasing the frequency of hydromill lifts and effectively extending the construction timeline while reducing labor needs.
Reduced Maintenance Needs: The hydromill module operates smoothly with minimal strain on the gearbox, which cuts down on both maintenance time and costs.
Minimal Ground Impact: This technology causes little ground disturbance, making it ideal for projects located in proximity to existing structures.
Improved Cutting Deflection: The design enhances the deflection capabilities during hydromill cutting in challenging rock formations.
High Precision: The vertical alignment of trenches can be maintained with an accuracy of up to 1‰, ensuring high-quality results.
Fuel Efficiency: The system achieves over 20% fuel savings (averaging 73L/h with a CAT C18 engine), making it more energy-efficient and environmentally friendly.
Module Parameter with SC-135
| Parameter | Specification |
| Total hydromill Module Weight | 47–60ton |
| Wall thickness | 1000–2000mm |
| Maximum Torque of Gearbox | 180KNm |
| Gearbox Output Speed | 0–20rpm |
| Maximum Pressing Force | 60 ton |
| Maximum Ground Pressure | 120 ton |
Module Parameters with XCMG 120
| Parameter | Specification |
| Total hydromill Module Weight | 47–60ton |
| Wall thickness | 1000–2000mm |
| Maximum Torque of Gearbox | 180KNm |
| Gearbox Output Speed | 0–20rpm |
| Maximum Pressing Force | 60 ton |
| Maximum Ground Pressure | 120 ton |
